Dual Port USB - 422/485 USB to 2 x RS422/RS485 Serial Ports (USB-422/485-2)

Manufacturer: SystemBase

Price: $69.00

Please note: This product echoes Tx characters automatically.

Highlights

Add 2 serial port to your PC easily!
RS422/ RS485(Combo) Serial Interfaces
Serial communication speed of up to 921.6Kbps
USB Version 1.1 compatible
Operates by bus power(Requires no external power)
RI signal line power supply
On-chip control for RS422/485 auto toggling
Built in 15KV ESD
Easy maintenance with TX/RX LED display
Windows 98/CE/2000/XP/Vista/2008/7, Linux Kernel 2.4 or greater, Mac OS X, Mac OS9, Mac OS 8.6 driver support

Multi-2/USB Series enables the connection of 2 asynchronous serial devices such as terminals, modems, printers, and scanners to make a PC an economical but a powerful multi-user and multi-device system. TXD and RXD LEDs are included for the displays of data transmission. Transmission speed rises up to 921.6Kbps per port, with the help of USB 1.1 specifications.

RS422/485 Interface Support

Multi-2/USB Series is composed of RS422 and RS485 (Combo) interface models. Serial communication speed of up to 921.6Kbps is supported to guarantee high performance. Auto-toggling on-chip controlled signal for RS422/485 provides precise line drivers control of input/output signals and realizes a stable communication. All RS232/422/485 transceivers are equipped with 15KVESD protection, providing electrical shock protection for the product.

BUS Interface

Bus Spec.

USB version 1.1 compliant

Serial

Interface	RS422 / RS485 (Combo)
No. of Ports	2 DB9 male
Speed	1200 bps to 921.6 Kbps
Signals	TX, RX, DTR, DSR, CTS, RTS, DCD, RI
Protection	15KV ESD Protection for all signals
Data Bits	5, 6, 7, 8
Stop Bits	1, 1.5, 2
Parity	None, Even, Odd, Space, Mark
Flow Control	RTS/CTS, XON/XOFF
