Three-Dimension Magnetometer Sensor Offers Low Cost, Instant Anti-interference
Advanced features eliminate drift while lowering cost for smart phones, tablets, gaming devices, digital compasses, GPS navigation, and augmented-reality applications.

Fairport, NY:  Saelig Company Inc ( has announced the IST8301C - a single-chip 3-axis digital magnetometer sensor, housed in an extremely small form factor (2.5 x 2.5 x 1.0mm) 12-pin BGA package.  The IST8301C is an integrated chip containing 3-axis magnetic sensors with an ASIC controller. The IST8301C outputs 13-bit data over a wide magnetic field range (+/- 1000uT) in a fast-mode 400kHz I2C digital output. The compact form factor is easily surface-mounted and is ideally suited to high-volume production consumer electronics, navigation systems, and magnetometers.

The IST8301C embeds 32 slots of 16-bit FIFO data for each of three output channels X, Y, Z. Since the host processor does not need to continuously read data from sensor, the FIFO’s “wake up only as needed” operation allows consistent system-power saving.  Functioning on 2.4V with a standby current of 10uA and full operation at 300uA, increased battery life can be attained in many portable applications.

The IST8301C offers a heading accuracy of +-1degree and a wide magnetic field range +/-10Gauss, while unique features of the 0.18um technology IST8301C include Anti-Offset and Anti-Temperature, eliminating errors caused by temperature and factory mismatch.  This allows for calibration-free designs unaffected by external interference: auto zero-drift eliminates errors from external magnetic sources. No more wrong tags on mobile phone and tablet images!

Costing much less than competitive products, iSentek’s IST8301C - already designed into overseas mobile phones and Windows 8 tablets - offers the best performance/cost solution available for smart phones, tablets, gaming devices, digital compasses, GPS navigation, and augmented-reality applications.

Designed and made in Taiwan by fabless MEMS IC design house iSentek, the IST8301C is available now from Saelig Company Inc. their North American distributor. Software and algorithm support and evaluation boards are also available.
