For Immediate Release February 8, 2008
New Product Press
Release
For Immediate Release February 8, 2008
Pittsford, NY: MSO5022 is a new, low-cost, full-featured 25MHz two-channel benchtop mixed-signal oscilloscope with 8-bit resolution, combined with a 16-channel logic analyzer - perfect for any engineer’s or student’s desk. USB connection makes printing stored results easy too. With a large 7.8” 640 x 480 color LCD, MSO5022 is small enough and light enough to carry anywhere you need. With a buffer size of 4Msamples, MSO5022’s timebase range is 5ns/div -5s/div, with synchronous 8-bit sampling on both channels. Sensitivity range is 5mV/div~5V/div with maximum display of ±50V. Signal triggering options include: Auto, Normal, Single, Edge, Video, and Alternate. Attractively housed in a 14.5” × 7” × 5.3” case and powered from 100-240 VAC 50/60 Hz, MSO5022 consumes less than 15W and weighs less than 2 pounds. The built-in 16-channel logic analyzer samples at 100MHz and pre-/mid-/re-triggers on: bus and state signature as well as, data width, and offers data search capabilities. Now you can see signals or data events on the same space-saving instrument!
MSO5022 can automatically measure and display frequency and peak-peak/rms/mean values, but cursors can also be moved to make individual readings. A built-in self-calibration facility improves measurement accuracy. Video monitoring is also possible since you can trigger on NTSC/PAL/SECAM line or field waveforms.
Another really useful feature is the ability to store 4 waveforms and settings
for comparison with live inputs. A persistence control is available too which
simulates old analog scopes to compare slow-moving waveforms with previous
scans. X-Y display allows you to see phase changes. A+B and A-B math
capability is also included. Accessories provided with the MSO5022 include two
x1/x10 passive oscilloscope probes (4 ft lead), logic probe, CD manual, PC
download software, and a USB cable.
Resembling much more expensive look-alikes, the MSO5022 Mixed Signal Oscilloscope offers unbeatable value and is available now at an introductory price of $799.00 from stock from Saelig Company Inc.
Hi-Res Image: http://www.saelig.com/images/mso5022hires.jpg
