ALFATxp FAT File System IC

Finally the long awaited for ALFATxp is available. This is our latest chipset to bring you FAT file system access to SD/MMC media. It also acts as a card reader though the built-in USB peripheral. Now, you can easily share files between a PC and your products.

Also, ALFATxp comes with a second USB interface so you can communicate with your product right from the PC. The interface is a CDC (Communication Device Class) which already has drivers on most operating systems. It also appears as a virtual COM port on a Windows environment and you can read/write data with easy serial communication protocol.

That is not all, this is our first chipset torun your Java code. There is no need for a second micro anymore. User programs can sit and run right inside ALFATxp.

• Java virtual Machine.
• All FAT, USB and peripherals are accessible from Java programs.
• FAT32, FAT16 and FAT12 support.
• Supports directories and sub-directories.
• Runs with simple robust protocol on UART, SPI or I2C.
• Can be easily used with any microcontroller including PIC, AVR.
• Supports MultiMedia Card (MMC) and Secure Digital (SD) memory cards.
• Simultaneous multi file access.
• Field upgradeable firmware.
• Firmware can be updated from a file on the connected media!
• Built in 10-bit ADC.
• USB device hardware.
• USB<->serial where serial protocol can be SPI, UART or I2C.
• All I/O pins are 5 volt tolerant.
• Very few external components are needed.
• Small LQFP 64 package.
• -40C to +85C temperature operating range.
• Lead free.

• Data Logger.
• Picture viewer.
• MP3 players.
• Digital cameras.
• Automated machines.
